ZTE GPON ONT F660 V6.0 (internal antenna)-Product Center-Benet Communication Co., Limited-

Name:	ZTE GPON ONT F660 V6.0 (internal antenna)

Product Description
Technical items	Descriptions
Model	F660 6.0
Out Port contains	1GE+3FE+1TEL+1USB+WiFi
WIFI signal	2.4GWiFi
Wireless gain	3db
USB	USB2.0
LAN	1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
TEL	H248/Sip Voice protocol
PPPOE	support
Firmware	English
Dimension/weight	180mm120mm35mm/256g
Fiber port	1 GPON interface, ingle-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength	Tx 1310nm, Rx 1490nm
Fiber interface	SC/FC-UPC/APC Dual mode/Singal mode
RX sensitivity	>-28dBm (1490nm)
DC power	12V 1.5A, external AC-DC power adapter
Button	Reset, power,LIGHT
Operation	Working temperature: -5- +55℃ working humidity:10-90%(non-condensation)
Storage	Storage temperature: -30℃- +60℃ storage humidity: 10-90%(non-condensation)

Feature
1.Plug-and-play: services can be deployed by one click on the NMS, and on-site configuration is not required.
2.Remote diagnosis: Remote fault locating is implemented by the loop-line test of POTS ports, call emulation and PPPoE dialup emulati
3.Link monitoring: E2E link detection is achieved using 802.1ag Ethernet OAM.
4.High speed forwarding: 900 Mbit/s forwarding in the NAT scenario.
5.IPv6 Capability: support IPv6/IPv4 dual stack and DS-Lite.
